Description
*Custom build only, call for lead time.
All heavy duty models include standard duty features plus inside vertical supports
Optional double bevel bolt-on edge, holes are punched in if ordered with bucket
Flat Face Couplers Included
Rated Operating Capacity
Heavy Duty 3000 lbs. +
Comes standard with cylinder guards
Includes all features of heavy duty buckets above
Removable bolt-on sides allow for extra capacity included – model #MS-KIT
Optional double bevel bolt-on edge, holes are punched in if ordered with bucket
Dual grapple hooks that operate independently, made from ½” grade 50 plate (30% stronger)

Specs
Brand
Messer Attachments
Model #
MBG66
Overall Width x Height
67" x 31"
Overall Depth
38"
Grapple Jaw Opening
44"
Cylinders/Cylinder Size
2 at 2" x 8" 3500 psi welded cross tube
Capacity/Struck (cubic ft)
15.9
Capacity/Heaped (cubic ft)
19.1
Approximate Weight (lbs)
925
Rated Operating Capacity
4,000 lbs
