Inverted Skid Steer Log Splitter – Power, Efficiency & Convenience
Splitting firewood doesn’t have to be a chore! The Inverted Skid Steer Log Splitter is designed for maximum efficiency, power, and convenience, allowing you to split logs without leaving the cab. With up to 32 tons of splitting force and a quick 7-second cycle time, this heavy-duty log splitter is built to handle even the toughest wood-splitting jobs. Its industry-first stackable serrated wedge design provides customizable splitting, while 4-way and 2-way wedge options allow you to adjust based on log size and density. The modular mounting plate can be positioned vertically or horizontally, offering versatility to match your workflow.
Key Features:
✅ Inverted Horizontal Splitter Orientation – Split logs directly on the ground, reducing heavy lifting and repositioning for faster, more efficient operation.
✅ Industry-First Stackable Serrated Wedge Design – Customizable wedge height and angles allow for precise and efficient log splitting.
✅ Modular Plate Mounting – Choose between vertical or horizontal mounting to match your work style and project needs.
✅ Includes 4-Way & 2-Way Wedges – Use the 4-way wedge for quick splitting of smaller logs or switch to the 2-way wedge for larger, denser wood.
✅ Heavy-Duty Hydraulic System – The powerful cylinders ensure fast and smooth splitting, handling logs up to 36 inches long with ease.
Model Options & Specifications:
Model
LS24
LS36
Part Number
901748
901749
Cylinder Size
4”
4.5”
Cylinder Stroke
24”
36”
Splitting Force
Up to 25 tons
Up to 32 tons
Length
82”
108”
Width
45”
45”
Height
25”
25”
Minimum Hydraulic Flow
10 GPM
13 GPM
Options
Factory Installed Couplers
Factory Installed Couplers
Shipping Weight
720 lbs.
830 lbs.
The Inverted Skid Steer Log Splitter is the perfect attachment for farmers, landowners, and firewood businesses looking to split wood faster, easier, and more efficiently. Whether you're working with small, easy-to-handle logs or large, dense hardwoods, this high-powered, durable splitter will get the job done—without the backbreaking labor!
